| • 4 ohms at < 1% THD+N: 100w x 2 RMS
• 2 ohms at < 1% THD+N: 145w x 2 RMS • 4 ohms bridged at < 1% THD+N: 290w x 1 RMS • Dynamic power: 580w • Die-cast aluminum heatsink • Illuminite circuit output (works with DUAL Illuminite speakers) • PWM MOSFET power supply • 2 Ohm stable stereo operation • Class A/B output design • Stereo/bridged simultaneous operation • Bridgeable operation • Direct wire connection terminals • Recessed front mounted controls | • Thermal overload protection
• Auto-reset speaker short circuit protection • Reverse polarity protection • Bi-color LED status indicator • Low level inputs (RCA) • High level inputs (speaker) • Variable input level control • Selectable crossover (high pass/low pass/full range) • Variable high pass crossover (XIA3145 and XIA4225 Only) • Variable low pass crossover • 12dB/Octave crossover slope (24dB on XIA5600) • 12dB Variable bass boost |
