| • Nominal Basket Diameter: 8”
• Nominal Impedance: 8 Ω • Power Rating: Peak 500 W, Watts 125 W • Resonance: 83 Hz • Usable Frequency Range: 90 Hz - 4.4 kHz • Sensitivity: 93.4 dB • Magnet Weight: 20 oz. • Voice Coil Diameter: 1.5” | • Recommended Enclosure Volume: Vented Acceptable
• Driver Volume Displaced: 0.02 cu.ft. / 0.58 liters • Depth: 3.6” • Shipping Weight: 4.8 lbs, 2.18 kgs • Ferrite Magnet Composition • Pressed Steel Basket • Treated Paper Cone Composition |
