| • 4 ohms: 220 watts x 2 channel
• 2 ohms: 280 watts x 2 channel • Bridged, 4 ohms, 560 watts x 1 channel • Max power output: 1250 watts • MOSFET power supply • Pulse width modulation circuitry • Remote bass level input (remote control included) • LED power indicators • Bass boost (0-24dB bass boost at 45Hz) • Tri-mode capable • 2/1 channel operation • 2 ohm stereo, 4 ohm mono stable | • 3-way system protection circuitry (short, thermal and overload)
• Gunmetal gray anodized finish with chrome accents • Heavy duty aluminum alloy heatsink • RCA level inputs • Screw terminals • Low level inputs (200mv-8v) • Variable high-pass filter (50-500Hz, 12dB/octave) • Variable low-pass filter (30-500Hz, 12dB/octave) • Subsonic filter (12dB at 30-175Hz) • Frequency response: 10-30,000Hz • Dimensions: 12.875"L x 10.625"W x 3"H |
