| • 4 ohms: 1200 watts x 1 channel
• 2 ohms: 1700 watts x 1 channel • 1 ohm: 2200 watts x 1 channel • Max power output: 4000 watts • MOSFET power supply • Wired remote bass level control included • LED power indicators • Bass boost (0-18dB bass boost @ 45Hz) • 180 degree phase shift • Pulse width modulation circuitry • Mono channel operation • Bridged synchronization (straps amps together to double power) | • Preamp RCA outputs
• 3-way system protection circuitry (short, thermal and overload) • Gunmetal gray anodized finish with chrome accents • Heavy duty aluminum alloy heatsink • RCA level inputs • Screw terminals • Low level inputs (200mv-8v) • Variable low- pass filter (40-200Hz, 12dB/octave) • Subsonic filter (12dB at 20-50Hz) • Frequency response: 15-150Hz • Dimensions: 14.875"L x 10.625"W x 3"H |
