| • 4 ohms: 140 watts x 2 channel
• 2 ohms: 180 watts x 2 channel • Bridged, 4 ohms: 350 watts x 1 channel • Max power output: 800 watts • MOSFET power supply • Pulse width modulation circuitry • Remote bass level input (remote level control included) • LED power indicators • Bass boost (0-18dB bass boost @ 45Hz) • Tri-mode capable • 2/1 channel operation • 2 ohm stereo, 4 ohm mono stable | • Preamp RCA outputs
• 3-way system protection circuitry (short, thermal and overload) • Gunmetal gray anodized finish with chrome accents • Heavy duty aluminum alloy heatsink • RCA level inputs • Screw terminals • Low level inputs (200mv-8v) • Variable high-pass filter (40-250Hz, 12dB/octave) • Variable low-pass filter (40-250Hz, 12dB/octave) • Subsonic filter (12dB @ 30-175Hz) • Frequency response: 10-30,000Hz • Dimensions: 10.875"L x 10.625"W x 3"H |
