| • Electrical Q value - QES: .32
• Mechanical Q value - QMS: 4.4 • Total speaker Q value - QTS: .30 • Free air resonance - FS: 30.6Hz • Equivalent compliance - VAS: 47.6 liters • One-way linear excursion - XMAX: 22mm | • Efficiency - SPL 1W/1M: 88.1 dB
• Effective piston area - SD: 480 cm • DC resistance - RE: 1.9 Ohm • Nominal impedance - Znom: dual 2 ohm • Thermal power handling - PE: 1000W • Force Factor - BL: 21 |
