| • Electrical Q value - QES: 29
• Mechanical Q value - QMS: 4.3 • Total speaker Q value - QTS: 27 • Free air resonance - FS: 30.7Hz • Equivalent compliance - VAS: 21.8 liters • One-way linear excursion - XMAX: 22mm | • Efficiency - SPL 1W/1M: 85.2dB
• Effective piston area - SD: 310 cm • DC Resistance - RE: 1.9 ohm • Nominal impedance - ZNOM: Dual 2 ohm • Thermal power handling - PE: 1000W • Force factor - BI: 21 |
