| • RMS @ 4 ohm: 4 x 80
• RMS @ 2 ohm: 4 x 95 • Bridged @ 4 ohm: 2 x 190 • Max power: 840w • Dimensions: 2”H x 9”W x 11.375” L • Brilliant silver texture coat finish • MOSFET power supply • Pulse width modulation circuitry • 3-way protection circuitry (short, thermal & overload) • 2 Ohm stereo, 4 ohm Bridged stable • Tri-mode capable | • Selectable Hi/Full/Low pass crossovers
• Pre-amp outputs • 200mV - 6V low level input sensitivity • Variable 12dB 30-250Hz LPF • Variable 12dB 50-500Hz HPF • Variable 0-12dB 45Hz Bass boost • Variable 12dB 15-50Hz subsonic filter • Frequency response: 10Hz - 30kHz • Signal-to-noise ratio: 97dB • Total harmonic distortion: .02% • 4 ga. power and 8 ga. speaker terminals |
