| • Max power: 700w
• RMS power: 300w • Magnet weight: 70 oz. • Fs: 27.5Hz • QMS: 5.290 • Vas: 2.122 • Xmax: 21.10mm • Qes: 0.793 • Qts: 0.690 • Efficiency: 83.9dB • Mounting depth: 6.125" • Dual 4 ohm KSV Kapton voice coils | • Polypropylene injection molded cone
• Butyl rubber surround • Nickel plated 8 ga. compression wire terminals • Poly-cotton spider • Texture coat finish on stamped steel basket • Suspension integrated tinsel leads • Vented back plate • Cutout diameter: 9.250" • Sealed enclosure: .75 • Ported Enclosure: 1.5 • Port: 3" x 9" |
