| • Max power: 1000w
• RMS power: 500w • Magnet weight: 80 oz. • Fs: 22.1Hz • QMS: 4.968 • Vas: 9.517 • Xmax: 24.00mm • Qes: 0.777 • Qts: 0.672 • Efficiency: 87.6dB • Mounting depth: 8.500" • Cutout diameter: 14" | • Sealed enclosure: 2.00
• Ported Enclosure: 4.00 • Port: (2) 4" x 11.75" • Dual 4 ohm KSV Kapton voice coils • Polypropylene injection molded cone • Butyl rubber surround • Nickel plated 8 ga. compression wire terminals • Poly-cotton spider • Texture coat finish on stamped steel basket • Suspension integrated tinsel leads • Vented back plate |
